LED WALL
CALCULATOR

HORIZONTAL

tiles

TILE WIDTH

px
mm

VERTICAL

tiles

TILE HEIGHT

px
mm

PIXEL PITCH

mm

TILE COUNT

16
full tiles
0
half tiles

FULL WALL

16:9 BOX

768 x 768
px
(1:1)
6′ 6.7″
wide
6′ 6.7″
high
768 x 432
px
6′ 6.7″
wide
3′ 8.3″
high

STANDARDS

4096 × 2160Contained
3840 × 2160Contained
2560 × 1440Contained
1920 × 1080Contained

INPUTS

DVI-D (SL)
1.32 Gb/s used of 9.90 Gb/s
HDMI 1.4 (SL)
1.32 Gb/s used of 9.00 Gb/s
HDMI 2.0 (SL)
1.08 Gb/s used of 14.83 Gb/s
DP 1.1 (SL)
1.32 Gb/s used of 9.00 Gb/s
DP 1.2 (SL)
1.32 Gb/s used of 19.80 Gb/s

E2 Gen2 | 60hz | Reduce Blanking V2

This is an estimate.

Always test on actual hardware before show.
